Hammer Mill
Reliable. Rugged. Versatile.
The MillNest Hammer Mill MHAM is designed for coarse to medium size reduction of dry, brittle, fibrous and spice materials. Built for high throughput, long service life and consistent particle size control.
50 – 5000
kg/hr Capacity Range
250 – 3000
Micron Typical Output
Up to 98%
Size Reduction
SS/ MS MOC
Options Available
ATEX / CE Certification
Options Available
The MHAM Hammer Mill uses a high-speed rotor fitted with swinging hammers to impact and break the material against a perforated screen. The final particle size is controlled by the screen aperture.
It is suitable for a wide range of materials in food, spice, nutraceutical, chemical and allied industries.
- Coarse to medium grinding in a single stage
- Interchangeable screens for output flexibility
- Rugged construction for continuous duty
- Low vibration and smooth operation
- Easy access for cleaning & maintenance
- ATEX design available on request
Use your mouse to move or zoom in the model
- Particle size range: 500 microns to 3mm
- Quick-change hammer system
- Multiple feed system options
- Variable speed control
- Stainless steel construction available
- Energy-efficient motor optimization
- Precision-balanced rotor assemblies
- Low vibration operation
- Dust-tight pneumatic discharge
- CE & ATEX compliance options
| Model | Capacity (kg/hr) | Motor Power (kW) | Dimensions L×W×H (m) | Feed Options |
|---|---|---|---|---|
| MHAM-500-40 | 100 – 500 | 5.5 – 30 | 1.24 × 0.9 × 1.0 | Gravity/Pneumatic/Screw |
| MHAM-1000-90 | 500 – 1000 | 37 – 60 | 1.8 × 1.1 × 1.7 | Gravity/Pneumatic/Screw |
| MHAM-2000-150 | 1000 – 2000 | 75 – 110 | 1.8 × 1.3 × 1.8 | Gravity/Pneumatic/Screw |
| MHAM-4000-300 | 2000 – 4000 | 125 – 225 | 2.7×1.4×2.0 | Gravity/Pneumatic/Screw |
The MHAM is suited for coarse to medium grinding across food, spice, nutraceutical and chemical industries. Screen-based particle control makes it reliable across varied material types.
- Chilli, turmeric, coriander, cumin & whole spices
- Dried herbs — parsley, basil, oregano, bay leaf
- Sugar, salt and dehydrated vegetable powders
- Grains, pulses and cereal ingredients
- Pharma excipients and nutraceutical blends
- Chemical powders and pigments (ATEX & Non-ATEX)
Hammer Mill Catalogue
Full technical specifications, dimensions and ordering information.
MHAM Datasheet
Full technical specifications, dimensions and ordering information.
Chilli & Spice Powders
Turmeric & Curcumin
Dehydrated Onion & Garlic
Dried Herbs & Botanicals
Pharma Granules
Grains & Dal
Besan & Pulse Flour
Chemical Powders
These four conditions indicate the MHAM Hammer Mill is the right starting point. Submit your material for a full review before final selection.
- You need high-throughput size reduction
- The target is coarse to medium powder
- Screen-based particle control is suitable
- A rugged first-stage grinder is required
Not sure if MHAM is right for your material?
Share your material details and our process experts will guide you to the right machine and process route.
Get expert guidance for your material, capacity and process requirement before committing to a machine.
